AIDA PTZ-NDI-X18B

Dostępność: Zapytaj o dostępność

Koszt wysyłki: od 20 zł

Numer katalogowy: PTZ-NDI-X18B

Stan produktu: Nowy

Gwarancja: Gwarancja 24 miesiące

Cena brutto: 5 064 zł

Cena netto: 4 117 zł

Ilość:

-+

szt.

Dodaj do koszyka

dodaj do schowka

Zapytaj o produkt Specyfikacja PDF

Opis produktu
SPECIFICATIONS
Linki (1)

AIDA PTZ-NDI-X18B

The most cost-effective NDI|HX PTZ to date

The PTZ-NDI-X18 is the perfect entry level PTZ for new, and existing live streaming productions. This PTZ comes equipped with a crystal clear 18X optical zoom, allowing for crisp 1080p imaging over HDMI, NDI|HX, and IP protocols simultaneously.
Pilot the PTZ with your standard VISCA, VISCA over IP, or NDI controllers. Overall, the PTZ-NDI-X18 gets the best NDI|HX performance per buck, without the compromise of video quality.

Main features:

NDI®|HX streaming capable for low latency video streaming and PTZ control.
Full HD Progressive Scan sensor captures sharp and vivid color under different light conditions.
Advanced digital image processor provides vivid and detailed images with full access feature sets.
Motion-compensated temporal noise reduction filter leads to effective noise reduction for motion video without blur.
Simultaneous IP and HDMI outputs for versatility and seamless video performance.
Power Optical Zoom capability up to 18X.
3.5mm Line-in for no audio/video delay over IP/NDI protocols.
Built-in OSD controls for customizable image settings.
Economically priced and perfect solutions for newer broadcast workflows.
Comes in either a White or Black shell for further customization

VIDEO

Image Sensor 1/3” Progressive CMOS
Effective Pixels Horizontal: 1920, Vertical: 1080
Pixel Size 2.13 μm (H) x 2.13 μm (V)
Resolution 1080p & 1080i: 1920 x 1080
Resolution Rate 1080 60p/59.94p/50p/30p/29.97p/25p
24p/23.98p
1080 60i/59.94i/50i
720 60p/59.94p/50p/30p/29.97p/25p
Output HDMI
NDI®|HX / RTSP / RTMP / SRT
Color Space 4:2:2 (YCbCr) 10bit
Min. Illumination 0.1Lux

FUNCTION

White Balance Auto, Manual, Auto Tracking, One Push,
Indoor, Outdoor
Focus Auto, Manua
Shutter Speed 1 to 1/10,000 Sec

LENS

Lens 18X HD Optical Zoom
Focal Length 5.2~93mm
F-Stop F1.5 ~ F3.0
Viewing Angle 60° (wide) ~ 4° (tele)

PTZ

Pan/Tilt Range Pan: 340°, Tilt: +90 to -30°
Pan/Tilt Speed Pan: 0° to +120°/s, Tilt: 0° to +80°/s
Presets 128 Positions (via web)
10 Positions (via remote)

STANDARD

IP Protocol UDP/IP, RTSP/RTMP

AUDIO

Input 3.5mm TRS Stereo Audio Port
Sample Rate 16/24/32 Bits

PHYSICAL

Camera Control Protocol: VISCA, VISCA over IP, NDI
Interface: RS-232C IN & OUT, RJ-45
Remote Controlle
Operation Temp 32°F - 104°F
Dimension 155mm x 160m x 170mm / 6.10” x 6.92” x 6.69”
Weight 1.35kg / 2.97lbs
Power 12VDC (+9 - +15VDC)
PoE+ (IEEE802.3at Standard Required
